USB Serial Adapter

FTDI FT232RL

Digikey Part# 604-00043-ND

ds_ft232r_v104.pdf

Prolific USB Serial Adapter

Drivers: http://www.prolific.com.tw/eng/downloads.asp?ID=31, Local copy

3.3V Logic

WireFunction
YellowDCD
BrownGround
OrangeRX (To Computer
PurpleRTS
RedTX (From computer)
BlueCTS
GreenRI??
GreyDTR

Reference
